|Product Name:||L Shaped Air Shower||External Size:||1500*2200*2440mm|
|Internal Size:||1130*1890*2190mm||Nozzle:||30 Pcs On Both Sides And Top|
|Blowing:||Three Sides Blowing(both Sides And Top)||Fans:||200 Centrifugal Fan 3 Sets *550W|
|Power:||1650W||Door Type:||One Manual Door And One Auto Sliding Door|
|Power Supply:||380V/50hz Or 220V/50hz Or 110V/60hz Or Customized||Hepa Filter And Pre Filter:||3 Sets|
l shaped air shower clean room,
pharmaceutical industry air shower clean room,
custom air shower in pharmaceutical industry
This is a customized L shaped air shower for the clean room at a special venue , the Enter door is a manual door and the Exit door is an automatic sliding door.The L type air shower is made of 304 SUS,External size is 1500*2200*2440mm,Three sides blowing(both sides and top), Total it has 30 pcs 360 degree rotating nozzles. We designed it according to the customer's requirements,we can accept OEM.
1. Enter the air shower from the non-clean area, induce blowing, and leave the air shower to the clean area.
2. Enter the air shower from the clean area, do not blow, and leave the air shower to the non-clean area.
NO. OF PERSONS PER CYCLE
Standard models are made only for 1 person per cycle. To meet the needs of large number of workers, we can also design air showers with 2, 3 and 4 persons per cycles. They can also be fitted in series and parallel to meet demand of large number of workers.
Our air showers are available of throughout type entry-exit, L type entry-exit and one-way entry and two way exit type.
Made of only corrosion resistant materials; we use either high grade stainless steel anti-microbial properties or powder coated MS for construction.
Two doors are fitted in a system, one at entrance and one at exit. Doors are also made of stainless steel or powder coated MS. Handles and hydraulic door closers are fitted for easy access of door. Electromagnetic interlocking allows opening of single at one time; thus, prevents unwanted contamination inside the machine. There is also emergency switch; by pressing it, both doors open immediately.
Properly balanced motor blower of standard make, fitted with suspension system for noise level reduction.
Flooring or platform is made of either Stainless steel or Aluminum with detachable anti-slip PVC mat or equivalent material.
Over all fittings such as handles, hinges and wires etc. are of any reputed brand and ISI marked.
Our engineering team visits your site and installs the machine properly. Demonstration and training is provided to all relevant staff.
|Product Name||Customized L Type Air Shower|
|Materials||Full 304 SUS or Powder coating steel|
|Blowing||Three sides blowing (Both sides and top)|
|Nozzles||30 pcs,Mounted on both sides and top.|
|Fan||3 sets 550W * 3|
|Hepa filter and Pre filter||3 sets|
|Door type||Enter door is the manual door and exit door is the automatic sliding door|
|Power supply||380V/50hz or 220V/50hz or 110V/60hz or customized|
|Work flow||Automatic induction voice prompt blowing.|
Packing and Shipping
Dongguan YANING Air Purification Equipment Manufacturing Co., Ltd. is a professional manufacturer of air purifying products. YANING specializing in producing person/cargo Air Shower, Pass Box, Clean Bench, Fan Filter Unit (FFU), HEPA filter air outlet, clean bench, clean room and hospital operating room supporting equipment.
YANING provide advanced, high quality products and perfect technical service to various industry applications, includes food, medicine, medical products production, laboratory, semiconductor production, biochemical technology, biotechnology, precision machinery, pharmaceuticals, and operating rooms in hospitals.
We are ISO9001:2015 certified company and our product passed CE, UL certification. YANING products are spreading throughout Asia, Europe, America, and Africa. No matter where you are, we are always at your side. You can trust us as long-term partner: YANING have ample products to satisfy your any demand from standard equipment and air filter to custom made purification equipment.
YANING insists on improving purifying equipment and air filter in order to reduce the work and maintenance cost. It let customer gain the steady efficiency and saves money, optimizing your project at the same time.
1.FFU ,air shower room ,cargo air shower ,HEPA filter ,Laminar flow clean bench ,pass box ,clean booth medical wash hand sink and Laminar flow ceiling ,all kinds of OT room equipments so on
2.primer,middle and HEPA filter ,sub-high efficiency filter
3. undertake 100-300 thousand class level clean room design and construction of the project commission inspection and maintenance.
