Home > products > Laminar Clean Bench > Vertical Laminar Clean Bench Air Flow Cabinet Clean Room 304SUS H13/H14 Efficiency

Vertical Laminar Clean Bench Air Flow Cabinet Clean Room 304SUS H13/H14 Efficiency

Product Details

Place of Origin: China

Brand Name: YN

Certification: CE/ISO

Model Number: YN-CB1500

Payment & Shipping Terms

Minimum Order Quantity: 1PCS

Price: Reconsideration

Packaging Details: Wooden case or as your requset

Delivery Time: 7-15 work days

Payment Terms: T/T, Western Union, , L/C, D/A

Supply Ability: 2000pcs/month

Get Best Price
Product Details
High Light:

laminar flow biological safety cabinet

,

laminar air flow cabinet

Product Name::
304 SUS Laminar Air Flow Cabinet
Size::
1500(W)*700(D)*1800(H)mm Or Custom
Material::
Full 304 Stainless Steel
Internal Size (W*D*H):
1400*680*540mm
Efficiency::
H13/H14
Cleanliness::
100 Class@ 0.3um(USD Fed Standard 209E)
Packaging:
Wooden Case Or As Your Requirement
Loading Port::
Shenzhen Or Guangzhou
Product Name::
304 SUS Laminar Air Flow Cabinet
Size::
1500(W)*700(D)*1800(H)mm Or Custom
Material::
Full 304 Stainless Steel
Internal Size (W*D*H):
1400*680*540mm
Efficiency::
H13/H14
Cleanliness::
100 Class@ 0.3um(USD Fed Standard 209E)
Packaging:
Wooden Case Or As Your Requirement
Loading Port::
Shenzhen Or Guangzhou
Product Description

304SUS Vertical laminar air flow cabinet clean room clean bench





1. Laminar airflow cabinet description:

The vertical laminar flow cabinet clean workbench is made up of indoor air filtered through a pre-filter, pressed into a static pressure tank by a centrifugal fan, and then filtered by a high-efficiency filter of air, and blown out from the air outlet of the air-efficient filter. Clean and uniform, it can eliminate the original air in the work area, and take away dust particles and biological particles to form a sterile and clean working environment.

It is widely used in scientific research and production departments such as medical and health, bio-pharmaceutical, food, medical science experiments, optics, electronics, laboratory testing, sterile microbial testing, plant tissue culture, etc., which require local clean and sterile working environment.



2.Clean bench features:

It is widely used in medical treatment, chemical experiment, electron, precise machinery, instrument, apparatus, medical preparation, operating room, foodstuff, drinks, daily-use cosmetic, stock raising and aviation, as well as providing germfree dustless clean environment.



>It can provide a clean area of Class A

>It can privide vertical or horizonal air flow without turbulence flow

>It can prevent the outside air get into the working area

>It is easy to control

>Customized design is welcome



3.Clean workbench parameter

Product Name Single horizontal clean bench Double horizontal clean bench Double vertical clean bench
Model YN-VC-001 YN-VC-002 YN-VC-003

(W×D×H)mm

External Dimension

1000*700*1800 1200*700*1800 1500*700*1800

(W×D×H)mm

Internal Work Zone

900*650*600 1100*650*600 1400*650*600
Clean Class Level 100Class 0.3µm(USA Federal Standard)
Rated Air Flow 1200m3/h 1800m3/h 2300m3/h
Air Velocity 0.3-0.6m/s 0.3-0.6m/s 0.3-0.6m/s
HEPA Efficiency 99.99% 0.3µm H13-H14
LUX ≥300lux ≥300lux ≥300lux
Power 124W 127W 200W
Noise ≤65dB ≤65dB ≤65dB
Power Supply 220V/50Hz 220V/50Hz 220V/50Hz
LED light 9W*1 13W*1 18W*1
Material Cabinet: epoxy powder coated steel or stainless steel, table-board: stainless steel

Customized design is welcome.



4.Use environment and conditions:

Temperature: 5°C∽35°C;
Relative humidity: no more than 85% (+35°C);
Pressure: 86kPa∽106 kPa;
The maximum dust concentration: 3500 particles / L (dust particle size not less than 0.5μm, 1300);
