GMP Self Cleaning Dynamic Pass Box 185W For Clean Room

  • GMP Self Cleaning Dynamic Pass Box 185W For Clean Room
  • GMP Self Cleaning Dynamic Pass Box 185W For Clean Room
  • GMP Self Cleaning Dynamic Pass Box 185W For Clean Room
  • GMP Self Cleaning Dynamic Pass Box 185W For Clean Room
  • GMP Self Cleaning Dynamic Pass Box 185W For Clean Room
  • GMP Self Cleaning Dynamic Pass Box 185W For Clean Room
  • GMP Self Cleaning Dynamic Pass Box 185W For Clean Room
Place of Origin CHINA
Brand Name YANING
Certification CE ISO SGS
Model Number YN-PBD-700
Minimum Order Quantity 1 SET
Price Reconsideration
Packaging Details The machine itself is first wrapped with plastic film, the four corners are protected by cardboard or protective foam, and then fixed in the pallet or wooden box.
Delivery Time 7 work days
Payment Terms Western Union, T/T, L/C
Supply Ability 100 units/Week
Product Details
Material Powder Coated Steel / SUS304 Material Thickness 1.2mm
Core Components Interlock Door, HEPA Filter Internal Work Zone (W*D*H) 700*700*700mm
External Dimension (W*D*H) 880*780*1300mm Voltage 220V/50Hz
Advantage Air Tight, Easy Clean Design HEPA Filter U15 (483x501x93mm)
HEPA Filter Efficiency 99.9995%@0.3um Blower Power 185W
Brand Name YANING CLEAR Place Of Origin Guangdong, China
High Light

Self Cleaning Dynamic Pass Box

,

GMP Dynamic Pass Box

,

185W Air Shower Pass Box
You can tick the products you need and communicate with us in the message board.
Model External Dimension(W*D*H) Internal Work Zone(W*D*H) Cabinet Material Inside Material HEPA Filter U15 Blower Power Sterilization Lamp Interlock system Power Supply
YN-PBD-500 680*580*1100mm 500*500*500mm Epoxy powder coated steel / Stainless steel Stainless steel 283*301*93mm 135W 8W Mechanical / Electronic 220V/50Hz
YN-PBD-600 780*680*1200mm 600*600*600mm Epoxy powder coated steel / Stainless steel Stainless steel 383x401x93mm 160W 8W Mechanical / Electronic 220V/50Hz
YN-PBD-700 880*780*1300mm 700*700*700mm Epoxy powder coated steel / Stainless steel Stainless steel 483x501x93mm 185W 8W Mechanical / Electronic 220V/50Hz
Leave a Message
Model External Dimension(W*D*H) Internal Work Zone(W*D*H) Cabinet Material Inside Material HEPA Filter U15 Blower Power Sterilization Lamp Interlock system Power Supply
Product Description

Product Description:

Dynamic Pass box is used in pharmaceutical classified area and designed to minimize traffic and cross contamination between two areas and at the same time transfer parts,tools, products etc. from one area to another area.
The unit acts as an air lock device preventing ambient air from entering, or clean air from exiting the clean room. It also help to prevent particulate contaminants from entering into a clean room & between different classified areas.

When transferring the goods, the fan collects the air from the inside and self-purifies the interior of the pass box through a HEPA filter at the top.The stable down-flow reduces the particulates on material surfaces and achieves Class 100 (ISO 5) air cleanliness.





Product Features:


1. Laminar flow design is adopted, and the air flowdirection is upper inlet and lower exhaust.
2. Wind speed: After passing through the high-efficiency filter, the wind speed is controlled at 0.38-0.57m/s
3. Pressure difference function: display filter pressure difference (range efficiency 0-500Pa), accuracy ±5Pa.
4. The high efficiency filter can be disassembled and assembled separately from the upper box,
which is convenient for maintenance and replacement.
5. Noise: Less than 65db during normal operation.
6. Custommade available upon customer’s requirement.



Optional Accessories:
1. LED Lamp or UV Lamp
2. Intercom system
3. Internal shelves
4. Buzzer system
5. Support stand or base box

GMP Self Cleaning Dynamic Pass Box 185W For Clean Room 0

GMP Self Cleaning Dynamic Pass Box 185W For Clean Room 1   GMP Self Cleaning Dynamic Pass Box 185W For Clean Room 2  GMP Self Cleaning Dynamic Pass Box 185W For Clean Room 3



Company Information


Dongguan YANING Air Purification Equipment Manufacturing Co., Ltd. is a professional manufacturer of air purifying products.
YANING specializing in producing person/cargo Air Shower, Pass Box, Clean Bench, Fan Filter Unit (FFU), HEPA Unit and other air cleaning equipment. We also produce G-level pri-filter, F-level medium filter, H-level HEPA filter and U-level ULPA filter.

YANING provide advanced, high quality products and perfect technical service to various industry applications, includes food, medicine,medical products production, laboratory, semiconductor production, biochemical technology, biotechnology, precision machinery, pharmaceuticals, and operating rooms in hospitals.

YANING insists on improving purifying equipment and air filter in order to reduce the work and maintenance cost.
It let customer gain the steady efficiency and saves money, optimizing your project at the same time.

We are ISO9001:2015 certified company and our product passed CE, UL certification. YANING products are spreading throughout Asia, Europe, America, and Africa. No matter where you are, we are always at your side. You can trust us as long-term partner:
YANING have ample products to satisfy your any demand from standard equipment and air filter to custom made purification equipment.


GMP Self Cleaning Dynamic Pass Box 185W For Clean Room 4

Production Capacity:

Product Line Production Line Capacity

Actual Units Produced
(Previous Year)

Air Shower,
Pass Box,
Clean Room,
Fan Filter Unit

Air Shower: 100 Pcs per Month;
Pass Box: 100 Pcs per Month;
Clean Room: 100 Pcs per Month;
Fan Filter Unit: 600Pcs per Month.

Air Shower: 1200Pieces;
Pass Box: 1200 Pieces;
Clean Room: 1200 Pieces;
Fan Filter Unit: 7200Pieces

Production Machinery:

Machine Name Brand & Model No. Quantity Number of Year(s) Used Condition
Laser Cutting Machine DN 400 2 3.0 Good
Bending Machine 100T/3200 5 5.0 Good
Welding Machine NBC-250F 16 7.0 Good
Punch Machine MASDA 1211 1 1.0 Good



GMP Self Cleaning Dynamic Pass Box 185W For Clean Room 5

CE CERTIFICATION:
GMP Self Cleaning Dynamic Pass Box 185W For Clean Room 6




Industry Exhibition:



GMP Self Cleaning Dynamic Pass Box 185W For Clean Room 7


FAQ
1. What is the main products your company is providing?
Our company specializes in purification equipment, including Air shower, Pass Box, Clean Bench, Laminar Air Flow,Fan Filter Unit and so on.

2. Do you have customize made products?
Yes. We could customized the products according to customer’s requirement.

3. How long is the leadtime?
About 10-20 days after payment according different order qty.

4. What is the form of payment?
T/T, L/C

5. What’s the packing?
The machine itself is first wrapped with plastic film, the four corners are protected by cardboard or protective foam,

and then fixed in the pallet or wooden box.
