Customized Modular Operating Room Hermetic Automatic Sliding Door Antibacterial Surface

The YN-OR-036 hermetic automatic sliding door is purpose-built for hospital operating room environments where airtight sealing, hygiene, and hands-free operation are critical. Its modular frame design integrates seamlessly with our electrolytic plate wall panel system for a complete, coordinated operating room solution.

• Airtight Hermetic Sealing: Quadruple-edge inflatable gasket system achieves EN 12207 Class 4 airtightness when closed, maintaining precise pressure differential between the operating room and adjacent areas — essential for infection control protocols.
• Touchless Multi-Mode Activation: Standard configuration includes microwave radar motion sensor, foot-activated switch, and wall-mounted push button. Optional elbow switch and remote control provide additional hands-free access methods for surgical teams.
• Antibacterial Stainless Steel Construction: Door leaf manufactured from 1.2mm SUS304 stainless steel with optional antibacterial powder coating or brushed finish. All surfaces are seamless and crevice-free for easy disinfection.
• Customizable Dimensions and Finish: Door width (900-1800mm), height (up to 2400mm), surface finish, and viewing window size are fully customizable to match your operating room specifications.
• Lead Shielding Option: For hybrid operating rooms with intraoperative imaging equipment, lead-lined door leaves providing up to 2.0mm lead equivalent radiation protection are available.

We provide complete installation documentation including frame mounting templates, electrical wiring diagrams, and commissioning checklists. Our technical support team can supervise on-site installation or provide remote video guidance. Each door is factory pre-tested for sealing performance and cycle endurance (≥500,000 cycles) before shipment, ensuring plug-and-play reliability at your facility.
