Product Details
Place of Origin: Guangdong, China
Brand Name: Yaning
Certification: ISO 9001:2015, CE
Model Number: YN-DB-1800
Payment & Shipping Terms
Minimum Order Quantity: 1 Set
Price: USD 4500-9800 / Set
Packaging Details: plywood
Delivery Time: 10-20 working days after order confirmation
Payment Terms: T/T,L/C,PayPal,Western Union
Supply Ability: 1500 Sets per Month
Cleanliness Class: |
ISO 5 (Class 100) |
Airflow Pattern: |
Vertical Unidirectional Downflow |
HEPA Filter Grade: |
H14 ≥99.995% At 0.3μm MPPS |
Material: |
304 Stainless Steel (SUS304) |
Surface Finish: |
Mirror-Polished Interior, Brushed Exterior |
Overall Dimensions (LxWxH): |
1800mm X 1500mm X 2350mm |
Working Area (LxWxH): |
1700mm X 1400mm X 1000mm |
Air Velocity: |
0.36-0.54 M/s Adjustable |
LED Illumination: |
≥800 Lux At Working Surface |
Noise Level: |
≤62 DB(A) |
Power Supply: |
380V/50Hz 3-Phase Or 220V/60Hz |
Cleanliness Class: |
ISO 5 (Class 100) |
Airflow Pattern: |
Vertical Unidirectional Downflow |
HEPA Filter Grade: |
H14 ≥99.995% At 0.3μm MPPS |
Material: |
304 Stainless Steel (SUS304) |
Surface Finish: |
Mirror-Polished Interior, Brushed Exterior |
Overall Dimensions (LxWxH): |
1800mm X 1500mm X 2350mm |
Working Area (LxWxH): |
1700mm X 1400mm X 1000mm |
Air Velocity: |
0.36-0.54 M/s Adjustable |
LED Illumination: |
≥800 Lux At Working Surface |
Noise Level: |
≤62 DB(A) |
Power Supply: |
380V/50Hz 3-Phase Or 220V/60Hz |
The YN-DB-1800 is a high-grade dispensing booth purpose-built for pharmaceutical powder handling and sterile compounding. Constructed entirely from premium 304 stainless steel with mirror-polished interior surfaces, it delivers exceptional durability, cleanability, and GMP compliance for regulated manufacturing environments.
Every structural component—frame, work surface, interior walls, and grille—is fabricated from SUS304 grade stainless steel. Mirror-polished interior with Ra ≤0.4μm surface roughness ensures no particle adhesion and effortless CIP cleaning.
HEPA H14 filter system delivers uniform unidirectional airflow at 0.45 m/s ±20%, creating a Class 100 working zone that exceeds ISO 14644-1 requirements.
High-CRI LED panel delivering ≥800 Lux at working surface with zero UV emission. Flicker-free operation suitable for precision weighing and visual inspection tasks.
Coved corners, flush-mounted fixtures, and seamless welding eliminate particle traps. Differential pressure monitoring ensures filter integrity throughout the production run.
From factory layout consultation and booth sizing to IQ/OQ/PQ validation documentation, we deliver a complete one-stop solution that reduces your vendor management burden.
