Product Details
Place of Origin: Guangdong, China
Brand Name: Yaning
Certification: ISO 9001:2015, CE
Model Number: YN-PCB-1200
Payment & Shipping Terms
Minimum Order Quantity: 1 Set
Price: USD 2800-6200 / Set
Packaging Details: plywood
Delivery Time: 5-10 working days for stock, 10-15 days for production
Payment Terms: T/T,L/C,PayPal,Western Union
Supply Ability: 5000 Sets per Month
Cleanliness Class: |
ISO 5 (Class 100) |
Structure Type: |
Soft-Wall With Rigid 304 SS Frame |
HEPA Filter: |
H14 ≥99.995% At 0.3μm MPPS |
Overall Size (LxWxH): |
1200mm X 900mm X 2000mm |
Working Area (LxWxH): |
1100mm X 800mm X 900mm |
Wall Material: |
Anti-Static PVC Curtain |
Air Velocity: |
0.45 M/s ±20% |
Setup Time: |
≤30 Minutes With 1 Person |
Power Supply: |
220V/50Hz Single Phase |
Weight: |
Approx. 85 Kg |
Mobility: |
4 Lockable Swivel Casters |
Cleanliness Class: |
ISO 5 (Class 100) |
Structure Type: |
Soft-Wall With Rigid 304 SS Frame |
HEPA Filter: |
H14 ≥99.995% At 0.3μm MPPS |
Overall Size (LxWxH): |
1200mm X 900mm X 2000mm |
Working Area (LxWxH): |
1100mm X 800mm X 900mm |
Wall Material: |
Anti-Static PVC Curtain |
Air Velocity: |
0.45 M/s ±20% |
Setup Time: |
≤30 Minutes With 1 Person |
Power Supply: |
220V/50Hz Single Phase |
Weight: |
Approx. 85 Kg |
Mobility: |
4 Lockable Swivel Casters |
The YN-PCB-1200 is the ultimate portable, plug-and-play clean room solution for laboratories, R&D centers, and small-batch production. Unpack, unfold the 304 stainless steel frame, hang the anti-static PVC curtains, plug into a standard wall outlet, and you have an ISO 5 clean workspace in under 30 minutes--no contractors, no construction, no downtime.
Portable Does Not Mean Compromised
The YN-PCB-1200 delivers genuine ISO 5 (Class 100) performance verified by independent particle count testing. Convenience without cutting corners --that's the promise.
